See you the example to understand how this feature works. If you specify source and destination addresses that belong to different VLANs, the Layer 2 path is not identified, and an error message appears. The traceroute mac command output shows the Layer2 path when the specified source and destination addresses belong to the same VLAN.
To do it, Cisco has implemented a good tool: traceroute mac. In a Data Center, it is often required to find a host and the layer2 path. Routers decrement this parameter and discard a packet when the TTL value has reached zero, returning an ICMP error message (ICMP Time Exceeded) to the sender.
Tracing the intermediate routers traversed involves control of the time-to-live (TTL) Internet Protocol parameter. Traceroute sends a sequence of Internet Control Message Protocol (ICMP) packets addressed to a destination host. Traceroute is a tool for measuring the route path and transit times of packets across an Internet Protocol (IP) network.
